42
CONTROLS AND FEATURES (Common)
Engine Cover Fixing Lever
(Front/Rear)
Latch/unlatch the engine cover fixing
lever t
o install or remove the engine
cover.
Tachometer
(equipped type
or optional
equipment)
The tachometer shows the engine
sp
eed in revolutions per minute.
Fuel Filler Cap (equipped type)
(with vent knob)
The fuel filler cap vent knob controls
air ente
ring and leaving the fuel tank.
When refilling the fuel tank, turn the
ve
nt knob counterclockwise to open
and remove the fuel filler cap.
Turn the vent knob clockwise and
close it
securely before transporting
or storing the fuel tank.
ENGINE COVER
FIXING LEVER
(front/rear)
UNLOCK
LOCK
FUEL FILLER CAP VENT KNOB
FUEL
FILLER CAP
OPEN
CLOSE
To Next Page
