TOHATSU BFT 75A - Fuel Gauge; Fuel Line Connector and Joint (Equipped Type)

43
CONTROLS AND FEATURES (Common)
Fuel Gauge
The fuel gauge indicates the fuel level
in the
tank.
Fuel Line Connector And Joint
(equipped type)
The fuel line connector and joint are
used to
connect the fuel line between
the fuel tank and the separate
outboard motor.
FUEL GAUGE
FUEL LINE CONNECTOR
(fuel tank side)
FUEL HOSE
FUEL LINE
JOINT
HOSE PLUG
HOSE CLAMP
(outboard motor side)
