68
STARTING THE ENGINE
2. Connect the fuel line to the tank.
Be sure the connector is securely
latched.
Always disconnect the fuel line
wh
en storing or transporting the
outboard motor.
3. Turn the fuel filler cap vent knob
counterc
lockwise all the way to
open the vent.
(Using the fuel tank mounted on
the boat)
1. Remove the hose plug from the
engine side fue
l hose. Insert the
fuel line joint into the engine side
fuel hose and secure it with the
hose clamp. (The procedure is the
same as in the case of using a fuel
tank equipped type. Refer to the
previous page.)
2. Insert another fuel line joint up to
the barb of the joint
in the fuel
tank side and secure it with the
hose
clamp (stainless steel type).
Refer to the owner’s manual for the
boat.
(fuel tank side)
FUEL TUBE ASSEMBLY
(equipped type) (outboard motor side)
FUEL HOSE
(tank side)
BARB
HOSE CLAMP
(stainless steel)
FUEL LINE CONNECTOR
(to fuel tank)
FUEL FILLER CAP
VENT KNOB
OPEN
To Next Page
