TOMAHAWK TW-9010
5. Connection of Central Lock
TOMAHAWK TW-9010 has in-built power relays for central lock control. Wiring for
connection of central lock is made in a separate six-pin socket. Wire colours and wiring diagrams
are shown in diagrams 1-4.
ATTENTION!
Please note that impulse duration for central lock control is a programmable function.
6. Setting Shock Sensor
S
etting is the last installation stage of TOMAHAWK TW-9010 alarm system. Set shock sensor
sensitivity to minimum. Gradually increase sensitivity and knock the car body with your palm to
check triggering threshold.
ATTENTION!
Excess sensitivity may result in a great number of false trigger actions; you will be forced to desensitize
sensors.
28
