11
STARTUP AND SETTING OF Ez Capture for DC-4
File name The setting here is applied to the Ez Capture saving file.
List :
This list includes items that may be used for file names.
List :
This list includes items used for file names. The items are used for file
names in order from top of the list.
• To add an item, select one from List and press the [Add ->] button
to add it to List .
• To delete an item, select one from List and press the [<- Delete]
button to delete it from List .
[Up][Down] button:
Click the [Up] button, and the item selected in List moves up by 1
step. Click the [Down] button, and the item selected in List moves
down by 1 step.
"Prefix, Digits of sequence number, Separator" column:
Specify "prefixes, digits of sequence number, and separators" respec-
tively as items used for file names.
Enter a prefix in a maximum of 12 alphanumeric characters.
Note that the signs "\ / : * ? " < > |" cannot be used.
Specify the minimum digit number for "Digits of sequence num-
ber". If the digits of the number to be added to a file name are
less than "Digits of sequence number", "0" will fill in the blanks at
the head portion of the number. If the digits of the number to be
added to a file name are more than "Digits of sequence number",
use the number without changing.
If numerals are missing in a sequence number, the missing por-
tion will be filled.
Setting example:
When items used for file names are "ID, name, date, time, procedure,
R/L", digits of sequence number "3", separators"_" and the file is saved
in the file format "JPEG", the file name (example) is as follows:
File format Select a file format from among the four file formats (JPEG, TIFF, PNG,
BMP). Click the radio button to select one.
For JPEG, quality setting is available. Select either High quality or
Standard quality.
Setting item Description
To Next Page
