42
Surveying
11. Setting Out Height Difference, Distance, and Elevation
You can locate ground points that correspond to entered numerical
data. The Set-Out menu provides three modes - height difference,
distance, and elevation.
11.1 Setting Out Height Difference
By entering the height difference (ΔH) from a benchmark
(point A), you can find a ground point (point B) at a specified
height difference from the benchmark.
The procedure below is for taking single measurements.
1 Set up the instrument between points
A and B.
2 In menu mode, select "Set-out", then
select "Ht-diff".
3 Input the height difference value that
you want to stake out.
DL502-503.book 42 ページ ２０１０年４月５日 月曜日 午前９時４７分
