16. SETTING-OUT ARC
4. Press [OK] to return to the screen
in step 2.
• [MOVE]: Permanently moves
the baseline coordinates by the
amount set in <Arcline offset>.
5. Press [OK] on the screen of step
2. The coordinate value of the
required point is calculated, taking
into account the movement of the
arcline, and displayed.
Set-out arc
E
N
Z
118.874
106.894
12.546
REC S-O
To Next Page
