103
17. POINT PROJECTION
• It is also possible to perform point projection measurement by pressing
[P-PROJ] when allocated to the OBS mode screen.
Allocating the function key: "31.3 Allocating Key Functions"
Before performing point projection, the baseline must be defined.
PROCEDURE
1. Define the baseline.
"17.1 Defining Baseline"
2.
Select "Point Projection" in <Point
Projection>.
3. Enter the point coordinate.
•Press [MEAS] to observe the
point to project.
• The tilt screen is displayed if the
instrument is out of level.
Level the instrument.
"7.2 Levelling"
•Press [REC] to record the data
as a known point.
Recording method:
"29.1 Registering/Deleting
Known Point Data"
17.2 Point Projection
Stn. Orien.
Define baseline
Point projection
Point projection
Point projection
Np:
Ep:
Zp:
12.152
103.514
101.423
C
RECLOAD MEAS OK
