37
SETTING
RGB setting
You can specify the color of the chart indicated by this instrument. You can set the color for the back-
ground and R/G chart on "Page 1", for the binocular function chart (black background type) on "Page
2" and for the binocular function chart (white background type) on "Page 3".
1. Background and R/G chart
You can change the background color for the visual acuity chart and astigmatism chart with RGB
full-color. In addition, you can change the red and green colors that are indicated on the red/green
test with RGB full-color.
2. Binocular function chart (black background type)
You can change the red and green colors that are indicated on the black background for the binocu-
lar function test with the RGB full-color. In addition, you can change the background color and
crossed area.
3. Binocular function chart (white background type)
You can change the red and green colors that are indicated on the white background for the binocu-
lar function test with the RGB full-color. In addition, you can change the background color and
crossed area.
Touch the [Default] button among the function buttons. You can return the contents changed on
the RGB setting screen to the setting when shipped.
