Topcon RL-100 2S User Manual

49
Detective
range
Mode
Display
HIGH NORMAL
Replacing Battery
1 Keep pushing the battery lid in [1] direction,
and then try to slide the lid in [2] direction to
lift.
2 Remove the batteries from the battery box
and insert new batteries (two AA dry
batteries).
3 Press the lid down and click to close.
±1 mm/±.0032 ft
(2 mm/.0064 ft width)
±2 mm/±.0064 ft
(4 mm/.013 ft width)
±5 mm/±.016 ft
(10 mm/.032 ft width)
±10 mm/±.033 ft
(20 mm/.066 ft width)
±15 mm/±.005 ft
(30 mm/.010 ft width)
More than ±15 mm/.05 ft
Laser sensor has been moved above or
below the laser beam.
Move sensor in direction of arrow to
receive laser.
[1]
[2]
