Topcon RL-100 2S User Manual

33
Maintaining Power Sources
How to Change Batteries on the Instrument
Dry battery
How to replace dry batteries
1 Remove the battery cover by turning the battery
cover knob to “OPEN”.
2 Remove the old batteries and replace with new
batteries (four D batteries) matching [+] and [-] as
shown in the figure.
3 Replace the battery cover and turn the knob to
“LOCK”.
Replace all 4 batteries with new ones.
Do not mix old batteries and new ones.

Topcon RL-100 2S Specifications

General

Brand	Topcon
Model	RL-100 2S
Category	Laser Level
Language	English
