Topcon System 150 User Manual

3-5
AGA3719 Rev 1.6
System 150 Auto Steer Setup Guide
Figure 3-8. Set A Point
4
The software will prompt you to set your A point. 4.
Once you have set the A point begin driving in a straight line at no 5.
faster than 2km/h
Figure 3-9. B Point appears after 70m
Drive approximately 70m and your B point will be set 6.
automatically
The speed of your vehicle must not exceed 2km/h
when performing the mounting bias calibration.
If this speed is exceeded, your calibration will
be unsuccessful and you will need to restart the
calibration process
NOTICE
NOTICE
