3-6
www.topconpa.com
System 150 Auto Steer Setup Guide
Figure 3-10. Perform keyhole turn
You will be prompted to perform a keyhole turn back to B 7.
After performing the keyhole turn, engage auto-steering drive back 8.
to point A
7
Ensure that Auto-Steering is engaged when
driving between the A and B points. Your
vehicle must steer along the line accurately for
the mounting bias calibration to be performed
successfully
It is recommended that a Mounting Bias
calibration be redone if the AGI-3 Antenna is
removed and mounted on a different tractor. This
is to prevent any possible errors due to possible
differences in the mounting position the AGI-3
Antenna
NOTICE
NOTICE
Upon reaching point A, you may be prompted to perform another
keyhole turn and drive back to point B. Continue following the on
screen prompts until your calibration progress reaches 100%.
