Toptech FCM II User Manual

Chapter 3 – Field Wiring
26
FCM II Installation Guide: 20160419 - Part # 2307
3.2.8 AC PERMISSIVE/STATUS WIRING (6ACIN)
Line
Block Valve
Status
VRU/VCU
Neutral
Ground/
Overfill
ESD
Note: This shows a typical configuration.
AC Permissive/Status inputs can be
assigned to any unused AC inputs.
Pump
Status
Etc.
Port 5 Input
Port 4 Input
Port 3 Input
Port 2 Input
Port 1 Input
Port 0 Input
Caution: The 6ACIN module is available
in 90-140 VAC and 180-250 VAC
models.
VERIFY MODULE VOLTAGE LISTED!!!
L N L N
A1 A2 A3 A4
   
Bottom Side
Bottom Row
Port 0
Port 1
L N L N
B1 B2 B3 B4
   
Bottom Side
Middle Row
Port 2
Port 3
L N L N
C1 C2 C3 C4
   
Bottom Side
Top Row
Port 4
Port 5
Terminal
Number
1 2 3 4
Figure 3.9 FCM II Field Wiring: AC Permissive/Status (6ACIN)
