43
FCM II Installation Guide: 20160419 - Part # 2307
6.2.2 30 INCH X 30 INCH PANEL
Figure 6.5 30 Inch x 30 Inch Panel Layout
The maximum number of FCM IIs on this panel is the equivalent of 18 single wide modules per row
(36 total).
Toptech recommends mounting the power supply on the DIN rail with the FCM IIs as most DIN rail
power supplies require vertical mounting and top/bottom clearance for proper cooling.
Each row of FCM IIs requires its own power supply.
