Toptech FCM II User Manual

Chapter 6 – Dimensions, Panel Layouts, Wiring
41
FCM II Installation Guide: 20160419 - Part # 2307
6.2 STANDARD PANEL DIMENSIONS
6.2.1 20 INCH X 20 INCH PANEL
Figure 6.3 20 Inch x 20 Inch Panel Layout

The maximum number of FCM IIs on this panel is the equivalent of 12 single wide modules.

Toptech recommends mounting the power supply on the DIN rail with the FCM IIs as most DIN rail
power supplies require vertical mounting and top/bottom clearance for proper cooling.
