Sensor is Defecve
Anymagnetcanbeusedtoverifywhetherornotthe
sensorisworking.Ifyoubringastrongmagnetnearthe
TRAYINorTRAYOUTsensorstheyshouldreturnTRUE.If
thesensorisworking,youcanskiptothe“Sensorisoutof
adjustment”secon.
Ifthesensorisnotworking,youwillneedtodetermine
whetherthesensoritselfisdefecveorifthereisashort
in the wiring.
NOTE: The TRAY OUT sensor is held in place by




Todisnguishbetweenawiringproblemandasensor
problem,youwillneedtoOhmoutthesensorwitha
mulmeter:
1. Removethemotorcover,thenremovethetopofthe
steppermotor’selectricaljunconbox:
2. Disconnectthe20pinMolexconnector.Thefemale
sidegoestothemotorandsensors:
3. Touchyourprobeleadstothepinscorrespondingto
thesensorofinterest:
