Thecontrolsowarerecordstheposionsofthetoolsin
thecarouselandspindleinaconguraonlewhenyou
shutthesowaredown.Ifyoufailtoshutthesoware
downbeforeturningothecomputer,orifyouhavea
powerfailureduringoperaon,thesowaremayrestart
withincorrecttoolposionsshownontheATCscreen.This
isaneasycondiontorecoverfrom.Performthefollowing
stepstocorrectthisproblem:
1. Ifthereisatoolinthespindle,removeitbefore
proceedingwithanATCrecovery.
2. Clickthe“TrayLoadPosion”buonontheATC
screen.
3. Usingthe“TrayFWD”or“TrayREV”buons,index
throughthetray.Usethe“Insert”and“Delete”
buonsontheManualLoad/UnloadseconoftheATC
controlscreenunlthetoolsthatarephysicallyinthe
traymatchupwiththetoolsshownontheATCcontrol
screen.
