10
SYMBOLOGY ON THE MACHINE
Symbol denoting the solution valve.
Indicates the solution valve lever.
Symbol denoting the suction motor.
Indicates the switch of the suction
motor.
Symbol denoting up-down of the
squeegee.
Indicates the squeegee lever.
Symbol denoting the charge level of
the batteries.
Indication of the maximum tempera-
ture of the detergent solution.
It is placed near the charging hole of
the solution tank.
Symbol denoting the open book.
Indicates that the operator has to
read the manual before the use of
the machine.
Symbol denoting the open book.
For the good functioning of the bat-
tery charger, read the manual of the
manufacturer.
Warning symbol.
Read carefully the sections marked
with this symbol, for the security of
both the operator and the machine.
Symbol that indicates the obligations
of disconnecting the system from the
batteries by disconnection the con-
nector before working on the ma-
chine.
Symbol that indicates the obligation of
wearing safety glasses.
Symbol that indicates the obligation
of wearing safety gloves.
Symbol preceding important infor-
mation about the correct use of the
machine.
Symbol that indicates operations that
have to be carried out only by quali-
ed personnel.
SYMBOLOGY HANDBOOK
Indicates the switch of the brush motor.
Symbol denoting the brake lever of the
emergency and parking brake.
Symbol denoting the selection switch of
the driving speed.
Symbol denoting the hour meter.
Symbol denoting the brake.
Indicates the signal lamp of the brake
on.
Symbol denoting the crossed bin. Indi-
cates that at the end of its activity, the
machine has to be disposed conform-
ing to the laws in force.
