Tornado OB 20/14 User Manual

6
SUMMARY
INTRODUCTORY COMMENT 5
GENERAL RULES OF SAFETY 7
Transfer 7
Storage and disposal 7
Correct use 7
Maintenance 7
LEGEND INSTRUMENT BOARD
AND CONTROLS 8
LEGEND MACHINE 9
SYMBOLOGY ON THE MACHINE 10
SYMBOLOGY ON THE MANUAL 10
BEFORE USE 11
Handling of the packed machine 11
Unpacking of the machine 11
Battery installation 11
Battery recharger 12
On-board battery recharger 12
Batteries recharging 12
Batteries recharging with on-board
charger 13
Batteries disposal 13
Batteries charge level indicator 13
Hour meter 14
Squeegee assembly 14
Adjustment of the squeegee 14
Pad assembly 15
FLOOR CLEANING 15
Connection of the batteries to the
machine 15
Recovery tank 15
Detergent solution tank 16
Starting of the machine 16
Forward movement 17
Speed adjustment 17
Working brake 17
Emergency brake 17
Adjustment of the base pressure 18
Overow device 18
Signal detergent solution reserve
(H2O on the display) 18
STOP OF THE MACHINE AFTER
CLEANING OPERATION 18
DAILY MAINTENANCE 19
Recovery tank cleaning 19
Suction lter cleaning 19
Pad disassembly 19
Squeegee cleaning 19
WEEKLY MAINTENANCE 20
Rear squeegee rubber check 20
Squeegee hose cleaning 20
Cleaning of solution tank and lter 20
TWO-MONTHLY MAINTENANCE 21
Front squeegee rubber check 21
TROUBLESHOOTING GUIDE 22
Signals on the display 22
The suction motor does not work 22
The base motor does not work 22
The traction motor does not work 23
Insufcient water on the base 23
The machine does not clean properly 23
The squeegee does not dry perfectly 23
Excessive foam production 23
PROGRAMMED MAINTENANCE 24
