QUICK REFERENCE − DECO 13A
en 300417 − 04/08 25
M/SRes
p.
NoteFunctionCode
M Modal Function. Function remains active until replaced by another
function of same group
S Sequential Function. Function remains active in programmed seg-
ment only.
DO Digital output
Resp. All functions with the (anticipated) response−enabling Yes in the
table above can be accompanied by one Parameter specifying
(Anticipated) Response Time [ms] of a particular item indepen-
dently of the override.
All M−functions are executed DURING the block. Put M−function in the next
block if you want it to be executed AFTER the block.
No block processing time is necessary for PNC−DECO and all synchros are
possible !
1 segment = 1 M−function.
All M−functions can be accompanied by Parameter W to shift the segment
in time [ms] at 100% override. But for all spindle functions, Parameter W is
disregarded !
