QUICK REFERENCE − DECO 13A
en 300417 − 04/08 24
M/SRes
p.
NoteFunctionCode
M883 Air OFF, LASER sens. 2 in MDI mode
M884 Air ON, LASER sensor 3 in MDI mode
M885 Air OFF, LASER sens. 3 in MDI mode
M886 Coolant ON + Flush pickoff−spindle
collet
Disable after 2 seconds, Timer T26
M887 ON Y4.3=1
Disable after 2 seconds
M888 ON Y4.1=1
Disable after 2 seconds
M889 ON Y5.6=1
Disable after 2 seconds
M890 ON Y5.4=1
(Spindle HF/NSK)
(DO1862)
M891 Disable Y5.4=0
(Spindle HF/NSK)
(DO1863)
M892 ON Y5.2=1
(Spindle HF/NSK)
(DO1864)
M893 Disable Y5.2=0
(Spindle HF/NSK)
(DO1865)
M894 ON Y5.0=1
(deep drilling pump)
(DO1866)
M895 Disable Y5.0=0 (DO1867)
