QUICK REFERENCE − DECO 13A
en 300417 − 04/08 23
M/SRes
p.
NoteFunctionCode
M825 Generate 100 [ms] impulse to enable
Socket 2 check. Check is over as
soon as code processing starts
(CO1774) no S
M831 Enable Output 1 on Optional Socket
3
(DO1803/
DO1805)
yes S
M832 Disable Output 1 on Optional Socket
3
(DO1803/
DO1805)
yes S
M833 Enable Output 2 on Optional Socket
3
(DO1804/
DO1806)
yes S
M834 Disable Output 2 on Optional Socket
3
(DO1804/
DO1806)
yes S
M835 Generate 100 [ms] impulse to enable
Socket 3 check. Check is over as
soon as code processing starts
(DO 1794) no S
M841 Enable output 1 on optional Socket 4 (DO1823/
DO1825)
yes S
M842 Disable output 1 on optional Socket 4 (DO1823/
DO1825)
yes S
M851 Enable output 1 on optional Socket 5 (DO1843/
DO1845)
yes S
M852 Disable output 1 on optional Socket 5 (DO1843/
DO1845)
yes S
M880 Air ON, LASER sensor 1 in MDI mode
M881 Air OFF, LASER sens. 1 in MDI mode
M882 Air ON, LASER sensor 2 in MDI mode
