QUICK REFERENCE − DECO 13A
en 300417 − 04/08 22
M/SRes
p.
NoteFunctionCode
M604 S6 spindle rotating ON (ccw)
M605 S6 Spindle OFF
M800 DO setting yes S
M801 Enforce new path creation Enter in a
separate block
and with no
parameters
no S
M811 Enable Output 1 on Optional Socket
1
(DO1763/
DO1765)
yes S
M812 Disable Output 1 on Optional Socket
1
(DO1763/
DO1765)
yes S
M813 Enable Output 2 on Optional Socket
1
(DO1764/
DO1766)
yes S
M814 Disable Output 2 on Optional Socket
1
(DO1764/
DO1766)
yes S
M815 Generate 100 [ms] impulse to enable
Socket 1 check. Check is over as
soon as code processing starts
(DO 1754) no S
M821 Enable Output 1 on Optional Socket
2
(DO1783/
DO1785)
yes S
M822 Disable Output 1 on Optional Socket
2
(DO1783/
DO1785)
yes S
M823 Enable Output 2 on Optional Socket
2
(DO1784/
DO1786)
yes S
M824 Disable Output 2 on Optional Socket
2
(DO1784/
DO1786)
yes S
