Greensmaster Flex 21 Groomer (Model 04201) (Rev. B)Page 8 – 5
Groomer Reel Mechanical Problems
Problem Possible Causes Correction
The groomer reel rotates when it is
in the raised, transport position.
The groomer reel should rotate
whenever the cutting reel is en-
gaged.
Normal operation.
No rotation of the groomer reel. Seized groomer reel or idler bear-
ing(s) in groomer side plate(s).
Broken or damaged idler spring.
The groomer belt is worn, broken,
or damaged.
Identify and replace faulty bear-
ing(s).
Replace spring.
If the belt slips, it probably is worn
and must be replaced.
Repair or replace belt if necessary.
A broken or worn belt could be the
result of improper belt routing or
seized bearings in groomer assem-
bly.
The turf is damaged or has uneven
grooming.
The groomer reel blades are bent,
damaged, or missing.
The groomer reel shaft is bent or
damaged.
Grooming depth is not equal on
both ends of groomer reel.
Repair or replace blades if neces-
sary.
Replace groomer reel shaft.
Adjust depth if necessary. Check
and adjust cutting unit set up (level
bedknife to reel, level rear roller to
reel, set height–of–cut, etc.).
Groomer
(Model 04201)
