Greensmaster Flex 21Traction and Reel Drive System (Rev. C) Page 4 – 2
Specifications
Item Description
Traction Drive Integral gearbox assembly attached directly to engine
Differential to traction drive has 8 mm pitch positive drive belts
Gearbox Fluid Dexron III Automatic Transmission Fluid (or equivalent)
Gearbox Fluid Capacity 2.9 qt (2.78 l)
Differential Integral in gearbox assembly
Brake Band drum (in gearbox)
Traction Drum Dual cast aluminum, 7.5 inch (19.1 cm) diameter
Reel Drive Gear driven countershaft (in gearbox) with cone wet clutch
Flexible coupler shaft used in reel drive system
Gearbox to reel drive has 8 mm pitch positive drive belts
