Greensmaster Flex 21 Traction and Reel Drive System (Rev. C)Page 4 – 1
Chapter 4
Traction and Reel Drive System
Table of Contents
SPECIFICATIONS 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL INFORMATION 3. . . . . . . . . . . . . . . . . . . . .
Check Gearbox Fluid 3. . . . . . . . . . . . . . . . . . . . . . . .
Gearbox Seals 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ADJUSTMENTS 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking Brake Cable Adjustment 4. . . . . . . . . . . . . .
Traction Control Cable Adjustment 4. . . . . . . . . . . .
Reel Control Cable Adjustment 5. . . . . . . . . . . . . . .
Traction Drive Belt Adjustment 6. . . . . . . . . . . . . . . .
Reel Drive Belt Adjustment 7. . . . . . . . . . . . . . . . . . .
Transmission Coupler Drive Belt Adjustment 8. . . .
SERVICE AND REPAIRS 9. . . . . . . . . . . . . . . . . . . . . .
Reel Drive and Transmission Coupler
Belt Replacement 9. . . . . . . . . . . . . . . . . . . . . . . . .
Reel Drive Assembly 10. . . . . . . . . . . . . . . . . . . . . . .
Reel Drive and Transmission Coupler
Bearing Housing 11. . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Drive Assembly 14. . . . . . . . . . . . . . . . . . . .
Traction Drive Belt Replacement 15. . . . . . . . . . . . .
Traction Drive Idler Pulley and Bearings 16. . . . . . .
Traction Drum Assembly (Serial Number
Below 240001001) 18. . . . . . . . . . . . . . . . . . . . . . .
Traction Drum Assembly (Serial Number
Above 240001000) 20. . . . . . . . . . . . . . . . . . . . . . .
Change Gearbox Fluid 23. . . . . . . . . . . . . . . . . . . . . .
Gearbox (Serial Number Below 240001001) 24. . .
Gearbox (Serial Number Above 240001000) 28. . .
Gearbox Assembly 30. . . . . . . . . . . . . . . . . . . . . . . . .
Differential Assembly 34. . . . . . . . . . . . . . . . . . . . . . .
Traction and Reel
Drive System
