Toro 21462 - Service Procedure Icons

ServiceProcedureIcons
ThefollowingiconsappearthroughoutthisServiceManualtobringattentionto
specicimportantdetailsofaserviceprocedure.
CriticalProcess
Thisiconisusedtohighlight:
•Installingsafetyequipment(shields,guards,seatbelts,brakes,andR.O.P .S.
components)thatmayhavebeenremoved
•Dimensionsorsettingsthatmustbemaintainedforpropermachineoperation
•Aspecicfastenertighteningsequence
•Componentorientationthatmaynotbeobvious
CriticalTorque
Thisiconisusedtohighlightanassemblytorquerequirementthatisdifferent
thanwhatisrecommendedintheStandardTorqueT ables.
FluidSpecications
Thisiconisusedtohighlightuidspecicationsandcapacitiesthatareless
common,andmaynotappearonthemachineservicedecalorinthemachine
Operator’sManual.
Note:RefertotheservicedecalonthemachineandthemachineOperator’s
Manualforcommonlyuseduidspecicationsandcapacities.
Preface
Page4
22InchAWD/RWDSteelDeckWalkPower
MowerServiceManual
3445-579RevA
