Toro 21462 - RWD Traction Cable Replacement

BrakeCableInstallation(continued)
g352637
Figure20
8.Modelsequippedwithelectricstartonly,connectthebatterybyinstalling
thepositivecablerst,thenthenegativecabletothebattery.Installthefoam
padandbatterycover.Securethebatterycoverwith2(M4.2x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
9.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
RWDTractionCableReplacement
RWDTractionCableRemoval
1.Parkthemachineonalevelsurface,stoptheengineandwaitforallmoving
partstostop.
2.Modelsequippedwiththe60vpowerhead,removetheharnessfrom
powerhead.
3.Modelsequippedwithelectricstartonly,removethe2(M4.2x2.0)
screwssecuringthebatterycover.Removethebatterycoverandfoampad.
Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
4.Removethegrassbaggerassemblyifattached.
5.Usinga3/8inchwrench,removethelocknutandcurvedwasherfromthe
cableanchor.
Controls:ServiceandRepairs
Page5–8
