UpperIntakeRemoval(continued)
g353303
Figure114
10.Removetheupperintakefromthedeck.
UpperIntakeInstallation
1.Positionthebladeoutofthewayofthelowerintake.
2.Installtheupperintakeontothedeck,securewith2(1/4x1.33inch)screws.
Torquethescrewsto3.39±0.45N•m(30±4in-lbs).
g353303
Figure115
3.Installthebottomintakecover,securewitha(1/4x1.33inch)screw.T orque
thescrewsto3.39±0.45N•m(30±4in-lbs).
4.Modelsequippedwithelectricstartonly,connectthebatterybyinstalling
thepositivecablerst,thenthenegativecabletothebattery.Installthefoam
padandbatterycover.Securethebatterycoverwith2(M4.2x2.0)screws.
Torquethescrewsto2.26±0.34N•m(20±3in-lbs).
5.Modelsequippedwiththe60vpowerhead,installtheharnesstothe
powerhead.
