g020435
Figure74
4.Iftheoillevelislow,removethellcap(Figure
10)andaddoiluntilitisbetweenthefulland
addmarks.Donotoverll.
5.Installtheoilllcapanddipstick.
6.Closetheenginecoverandsecureitwiththe
latches.
CrankcaseOilCapacity
5.7L(6quarts)
ServicingtheEngineOilandFilter
ServiceInterval:Every250hours
Changetheoilandlterevery250hours.
1.Removethedrainplug(Figure75)andlettheoil
owintoadrainpan.Whenalltheoilisdrained,
installthedrainplug.
g020434
Figure75
1.Engineoildrainplug
2.Removetheoillter(Figure76).Applyalight
coatofcleanoiltothenewltersealbefore
screwingiton.Donotovertighten.
g020436
Figure76
1.Engineoillter
3.Addoiltothecrankcase;refertoCheckingthe
EngineOil.
Servicingthe
Diesel-OxidationCatalyst
(DOC)andtheSootFilter
ServiceInterval:Every6,000hoursorcleanthesoot
lterifenginefaultsSPN3720FMI
16,SPN3720FMI0,orSPN3720FMI
16displayintheInfoCenter.
•IfadvisorymessageADVISORY179displaysinthe
InfoCenter,theDPFisnearingtherecommended
pointforservicingthediesel-oxidationcatalystand
thesootlter.
g213865
Figure77
•IfenginefaultsCHECKENGINESPN3251FMI0,
CHECKENGINESPN3720FMI0,orCHECKENGINE
SPN3720FMI16intheInfoCenter(Figure78)
displayintheInfoCenter,cleanthesootlterusing
thestepsthatfollow:
