Toro 30606 - Servicing the Engine Fuel Filter

2.Loosenthedrainplugonthebottomofthelter
canisterandopentheventonthetopofthe
canistermount.
g007367
Figure79
1.Waterseparatorltercanister
3.Cleantheareawheretheltercanistermounts.
4.Removetheltercanisterandcleanthe
mountingsurface.
5.Lubricatethegasketontheltercanisterwith
cleanoil.
6.Installtheltercanisterbyhanduntilthegasket
contactsmountingsurface,thenrotateitan
additional1/2turn.
7.Tightenthedrainplugonthebottomofthelter
canisterandclosetheventonthetopofthe
canistermount.
ServicingtheEngineFuel
Filter
ServiceInterval:Every400hours
Theenginefuelltershouldbereplacedafterevery
400hoursofoperation.
1.Cleantheareaaroundthefuellterhead(Figure
80).
g021291
Figure80
1.FuelFilterhead2.FuelFilter
2.Removethelterandcleanthelterhead
mountingsurface(Figure80).
3.Lubricatetheltergasketwithcleanlubricating
engineoil.RefertotheEngineOperator's
Manual,includedwiththemachine,foradditional
information.
4.Installthedryltercanister,byhand,untilthe
gasketcontactsthelterhead,thenrotateitan
additional1/2turn.
5.Starttheengineandcheckforfuelleaksaround
thelterhead.
56
