Toro 34225 - Removing and Installing the Battery

ChargingtheBattery
WARNING
Chargingthebatteryproducesgassesthat
canexplode.
Neversmokenearthebatteryandkeepsparks
andamesawayfrombattery.
Important:Alwayskeepthebatteryfullycharged
(1.265specicgravity)topreventbatterydamage
whenthetemperatureisbelow32°F(0°C).
1.Removethebatteryfromthechassis;referto
RemovingtheBattery(page59).
2.Checktheelectrolytelevel.
3.Ensurethatthellercapsareinstalledonthe
battery.
4.Chargethebatteryfor1hourat25to30Aor6
hoursat4to6A.
5.Whenthebatteryisfullycharged,unplugthe
chargerfromtheelectricaloutlet,anddisconnect
thechargerleadsfromthebatteryposts(Figure
77).
6.Installthebatteryontothemachineandconnect
thebatterycables;refertoInstallingtheBattery
(page60).
Note:Donotrunthemachinewiththebattery
disconnected;electricaldamagemayoccur.
g000538
Figure77
1.Positivebatterypost
3.Red(+)chargerlead
2.Negativebatterypost
4.Black(-)chargerlead
RemovingandInstalling
theBattery
RemovingtheBattery
WARNING
Batteryterminalsormetaltoolscouldshort
againstmetalmachinecomponentscausing
sparks.Sparkscancausethebatterygasses
toexplode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
machine.
WARNING
Incorrectbattery-cableroutingcoulddamage
themachineandcablescausingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative-battery
cable(black)beforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive-batterycable
(red)beforeconnectingthenegative
(black)cable.
1.Preparethemachineformaintenance;referto
PreparingtheMachine(page51).
2.Removethebatterycover(Figure76);referto
step2ofCheckingtheBatteryCharge(page
58).
3.Removethehex-angedboltandangednut
fromthenegative-batterycableandnegative(-)
batteryterminal,andremovethecablefromthe
battery(Figure78).
