ReplacingtheTractionBelt
g300570
Figure69
1.Tractionbelt4.Idlerpulley
2.Insertratchethere.5.Enginepulley
3.Pumppulley
RemovingtheTractionBelt
1.DisconnectthePTOshaftfromtheattachment
gearbox;refertoyourattachmentOperator’s
Manual.
2.Unplugtheclutch-wire-harnessconnectorfrom
themachinewireharness(Figure70).
g300592
Figure70
1.Clutchwireharness
3.Bolt,washer,andnut
2.Rubberstrap
3.Removethebolt,washer,andnutfromthe
rubberstrap(Figure70)ontheframe.
4.Haveanassistantusearatchettorelease
tensionfromthebelt,thenremovethebeltfrom
thepumppulley,idlerpulley,andenginepulley.
5.Movethebeltovertheclutchandforwardonthe
PTOshaft.
InstallingtheTractionBelt
1.MovethebeltalongthePTOshaft,overthe
clutch,andontotheenginepulley..
2.Haveanassistantusearatchettopulltheidler
pulleydown.
3.Routethebeltontheenginepulley,idlerpulley,
andpumppulley(Figure69).
4.Removetheratchetfromtheidlerarm.
5.Usethepreviouslyremovedbolt,washer,and
nuttosecuretheendoftherubberstraptothe
frame.
6.Plugintheclutch-wire-harnessconnectortothe
machinewireharness.
56
