Toro Groundsmaster 360 Series - Page 23

g321246
g321244
Figure32
1.Deckshim3.Beltcover
2.Inner-channeltab(outer
deck)
2.Installthedeckshimsatthefrontofthedeck
asshowninFigure33.
g321239
Figure33
1.Beltcover3.Deckshim
2.Inner-channeltab(outer
deck)
Note:Ifyouareusingfeelergauges,usea
pieceoftapetoadhereafeelergauge—0.15
mm(0.060inch)tothetaboftheinnerchannel
(Figure34).
