Toro Groundsmaster 360 Series - Tensioning the Chains

g321243
Figure34
1.Inner-channeltab
3.Frontofthemachine
2.Feelergauge
4.Backofthemachine
3.Starttheengine,fullyraisetheleftandright
decks,shutofftheengine,removethekey,and
waitforallmovingpartstostop.
TensioningtheChains
1.Atthefrontofthedeck,tightentheoutboard
serrated-angenutsuntilthechainsare
tensioned(Figure35).
Note:Ensurethatthedeckshim(orfeeler
gauge)contactsthenpivotlink.
Important:Ensurethattheupperandlower
serrated-angenutpairsareadjustedevenly.
g321234
Figure35
1.Deckshim(orfeeler
gauge)
5.U-bolt
2.Serrated-angenut
(outboard)
6.Frontofthemachine
3.Pivotlink
7.Serrated-angenut
(inboard)
4.Chain(limit)
2.Threadtheinboardserrated-angenuts(Figure
35)andtorquethemto103to127N∙m(76to
94ft-lb).
3.Atthebackofthedeck,tightentheinboard
serrated-angenutsuntilthechainsare
tensioned(Figure36).
Note:Ensurethatthedeckshim(orfeeler
gauge)contactsthenpivotlink.
Important:Ensurethattheupperandlower
serrated-angenutpairsareadjustedevenly.
