Toro RT600 - Servicing the Air-cleaner System; Installing the Air-cleaner Cover; Replacing the Primary Element; Replacing the Secondary Element

InstallingtheAir-cleanerCover
1.Alignthedustcapontheair-cleanercovertothe7
o’clockposition.
2.Aligntheair-cleanercoverontothecleanerhousing.
3.Rotatetheair-cleanercoverclockwisesothatthedust
capisatthe8o’clockposition(Figure45).
4.Pushthelatchfortheair-cleanercoverinwarduntilthe
coverisfullyseated(Figure45).
5.Installtheleftsidepanel;refertoInstallingtheSide
Panels(page36).
ReplacingthePrimaryElement
Important:Replacetheprimaryair-cleanerelement
whentherestrictedair-cleanerlightcomeson.
1.Removetheair-cleanercover;refertoRemovingthe
Air-cleanerCover(page40).
2.Pulltheprimaryair-cleanerelementoutwardand
removeitfromtheair-cleanerhousing(Figure48).
Figure48
1.Primaryair-cleanerelement
Note:Discardtheoldair-cleanerelement.
3.Useacleandampclothtocleantheinsideofthe
cleanerhousing.
4.Usealighttoinspectthenewelementfordamage;if
theelementisdamaged,replaceit.
Note:Checkthedateofmanufactureontheendof
thenewair-cleanerelement.Donotinstallanelement
thatismorethan5yearsold.
5.Writethecurrentdateandtheenginehoursontheend
oftheelementwithapermanentmarkingpen.
6.Insertthenewprimaryair-cleanerelementintothe
air-cleanerhousing(Figure48).
Note:Ensurethattheair-cleanerelementisfully
seatedinthehousing.
7.Installtheair-cleanercover;refertoInstallingthe
Air-cleanerCover(page41).
8.Checktherestrictedair-cleanerlight;refertoChecking
theRestrictedAir-cleanerLight(page40).
ReplacingtheSecondaryElement
Note:Replacethesecondaryair-cleanerelementafteryou
havereplacedtheprimaryair-cleanerelement3timesorif
theair-cleanerrestrictionlightcomesonwhiletheengineis
runningandyouhavealreadyreplacedprimaryair-cleaner
element.
Important:Donotcleaneithertheprimaryelement
orthesecondaryelement.
1.Removetheair-cleanercover;refertoRemovingthe
Air-cleanerCover(page40).
2.Pulltheprimaryair-cleanerelementoutwardand
removeitfromtheair-cleanerhousing;referto
ReplacingthePrimaryElement(page41).
Pullthesecondaryair-cleanerelementoutwardand
removeitfromtheair-cleanerhousing.(Figure49).
Figure49
1.Secondaryair-cleanerelement
Note:Discardtheoldair-cleanerelement.
3.Cleantheinsideofthecleanerhousingwithaclean,
dampcloth.
4.Insertthenewsecondaryair-cleanerelementintothe
air-cleanerhousing(Figure49).
