Toro RT600 - Electrical System Maintenance; Replacing a Fuse

BatteryChargingTable
ChargerSettingChargingTime
4to6amperes30minutes
25to30amperes10to15minutes
5.Whenthebatteryisfullycharged,unplugthecharger
fromtheelectricalsource,thendisconnectthecharger
leadsfromthebatteryposts(Figure57).
ReplacingaFuse
1.Removetherightsidepanel;refertoRemovingthe
SidePanels(page35).
2.Rotatethebattery-disconnectswitchcounterclockwise
totheOffposition(Figure58).
Figure58
1.Battery-disconnectswitch
intheOnposition
2.Battery-disconnectswitch
intheOffposition
3.Replacetheopen(blown)fuseinthefuseblockwitha
newfusethathasanequivalentamperagevalue(Figure
59).
Figure59
1.Fuseblock
4.Rotatethebattery-disconnectswitchclockwisetothe
Onposition(Figure17).
5.Installtherightsidepanel;refertoInstallingtheSide
Panels(page36).
47
