Figure3
1.Wheelassembly
3.Wheelstud(rearwheel
hubshown)
2.Wheelnut
2
InstallingtheSteeringWheel
Partsneededforthisprocedure:
1
Steeringwheel
Procedure
Note:ThisprocedureisonlyneededforModelNo.
07277TC.
1.Removethenutandwasherfromthesteeringshaft.
2.Slidethesteeringwheelandwasherontotheshaft.
Positionthesteeringwheelontheshaftsothatthe
crossbeamishorizontalwhenthetiresarepointed
straightaheadandthethickerspokeofthesteering
wheelisdownward.
3.Securethesteeringwheeltotheshaftwiththenut
(Figure4).Torquethenutto18-22ft-lb(24-29N-m)
Figure4
1.Steeringwheel
3.Washer
2.Nut4.Foamseal
3
InstallingtheBumper
Partsneededforthisprocedure:
1Bumper
Procedure
Note:ThisprocedureisonlyneededforModelNo.
07277TC.
1.Removethe2bolts,washers,andnutssecuredtothe
frontoftheframe.
2.Alignthemountingholesandsecurethebumper
totheframewiththefastenerspreviouslyremoved
(Figure5).
Figure5
1.Bumper
4
InstallingtheSeats
Partsneededforthisprocedure:
2
Seat
Procedure
Note:ThisprocedureisonlyneededforModel
No.07277TC.
Inserttheseatbracketintotheseatbaseopeningand
pivottheseatdownward(Figure6).
11
