DriveSystem
Maintenance
CheckingandAdjusting
Neutral
Whenperformingroutinemaintenanceand/orengine
diagnostics,thetransaxlemustbeshiftedintoneutral
(Figure40).Thevehiclehasaneutralpositiononthe
shiftlever,whichcontrolstheneutralinthetransaxle.
Thefollowingstepsshouldbetakentomakesurethat
theneutralshiftleveroperatesthetransaxleneutral
correctly:
1.SettheshiftleverintotheNeutralposition.
2.Ensurethattheneutralbracketisintheneutral
position(level)byturningthedriveclutch
(Figure40).Thevehicleshouldnotrollbackand
forth.Ifitdoes,manuallymovetheneutralbracket
totheneutralposition.
G002093
1
2
Figure40
1.Neutralbracket2.Locknuts
3.Tightenoneofthelocknuts(Figure40)justenough
totaketheslackoutoftheshiftcable.
Note:Youmustholdthethreadedshaftbelowthe
brackettotightenthelocknutontop.
4.Tightentheotherlocknutjustenoughtotakethe
slackoutoftheothershiftcable.
5.Pulluponeachshiftcableanensurethatthereisno
gapbetweenthenut/washerandtheneutralbracket
(Figure41).Ifthereisagap,tightenthenut.
Figure41
1.Neutralbracket4.Wrong,musttightenthe
nut
2.Pullup
5.Correctadjustment
3.Cableboot
6.StarttheengineandshiftintoForward,Reverse,
andNeutralseveraltimestoensurethattheneutral
bracketisoperatingproperly.
InspectingtheTires
Checkthetireconditionatleastevery100hours
ofoperation.Operatingaccidents,suchashitting
curbs,candamageatireorrimandalsodisruptwheel
alignment,soinspecttireconditionafteranaccident.
Checkthewheelstoensurethattheyaremounted
securely.Torquethelugnutsto45-65ft-lb(61-88N-m).
AdjustingtheFront
Suspension
Therideheightofeachsideofthevehiclecanbe
adjustedseparately.Therideheightshouldbe8-3/4
to9-1/2inches(22.2to24cm)withthefollowing
parameters:
•Thetirepressureshouldbeat12psi(83kPa).
•Thevehicleshouldbedrivenbackandforthafew
timestorelaxtheA-arms.
•Measuretherideheightwiththewheelsfacing
straightaheadanda175-225lb(79-102kg)operator
inthedriver’sseat.
Note:Thedrivershoulddriveuptothe
measurementareaandstayseatedinthevehicle
whilethemeasurementisbeingtaken.
•Measuretherideheightonaatsurface,fromthe
bottomofthefronttonguetotheground.
1.Jackthefrontendofthevehicleoffoftheground;
refertoJackingtheVehicleinPremaintenance
Procedures,page27.
2.Removethetravellimitingbolt(Figure42).
34
