Figure6
1.Seatbracket2.Seatbase
5
InstallingtheHitch
Partsneededforthisprocedure:
1Hitch
Procedure
Note:ThisprocedureisonlyneededforModelNo.
07277TC.
1.Removethe4boltsandnutsfromtheinsiderear
oftheframe.
2.Alignthehitchwiththemountingholesonthe
frame.Securethehitchwiththescrewsandnuts
(Figure7).
Figure7
1.Hitch
6
InstallingtheCargoBox
Partsneededforthisprocedure:
1
Cargobox
1Right-handpivotbracket
1
Left-handpivotbracket
4
Flangeheadscrew(3/8x1inch)
1
Bolt(5/16x3/4inch)
1
Flangenut(5/16inch)
Procedure
Note:ThisprocedureisonlyneededforModel
No.07277TC.
1.Positionthecargoboxontotheframe.Thecargo
boxmustlayatandbecentered.
2.Mountthelefthandpivotbrackettotheleftrear
corneroftheframewith2angeheadscrews(3/8x
1inch).PositionthebracketasshowninFigure8.
12
