Figure8
1.Pivotbracket
3.Slidethecargoboxmountingholeontothepivot
bracket(Figure9).
Figure9
1.Cargobox3.Cargoboxmountinghole
2.Pivotbracket
4.Inserttherighthandpivotbracketintothemounting
holeinthecargoboxandthenmountittotheframe.
5.Haveanotherpersonhelptoraisethecargobox.
6.Loosentheboltsecuringtheproprodcliptothe
frameuntilyoucanslidetheJ-hookendoftheprop
rodundertheclip(Figure10).
Figure10
1.Proprod
3.Bolt(5/16x3/4inch)
2.Proprodclip
4.Flangenut(5/16inch)
7.Tightentheboltandsecuretheothersideoftheclip
withanewbolt(5/16x3/4inch)andangenut
(5/16inch)(Figure10).
8.Lowerthecargobox.
7
ActivatingtheBattery
NoPartsRequired
Procedure
None
Note:ThisprocedureisonlyneededforModelNo.
07277TC.
Ifthebatteryisnotlledwithelectrolyteoractivated,it
mustberemovedfromthevehicle,lledwithelectrolyte,
andcharged.Bulkelectrolytewith1.260specicgravity
mustbepurchasedfromalocalbatterysupplyoutlet.
1.Removethebatteryhold-downandliftthebattery
outofthebatterybase.
Batteryelectrolytecontainssulfuricacidwhich
isadeadlypoisonandcausessevereburns.
•Donotdrinkelectrolyteorallowittocontact
yourskin,eyesorclothing.Wearsafety
glassestoshieldyoureyesandrubbergloves
toprotectyourhands.
•Fillthebatterywherecleanwaterisalways
availableforushingtheskin.
2.Removethellercapsfromthebatteryandslowly
lleachcelluntilelectrolyteisjustabovetheplates.
13
