withalightloadmostofthetime,setthetoe-inon
thelowsideoftherecommendedamount.
1.Ensurethatthefrontsuspensionisadjusted
properly;refertoAdjustingtheFrontSuspension.
Adjustifnecessary.
2.Measurethedistancebetweenbothofthefronttires
attheaxleheightatboththefrontandrearofthe
fronttires(Figure44).Axtureoralignmentgauge
isneededfortherearmeasurementofthefronttires
ataxleheight.Usethesamextureoralignment
gaugetoaccuratelymeasurethefrontofthefront
tiresataxleheight(Figure44).
Figure44
1.Tirecenterline-back4.Fixture
2.Tirecenterline-front
5.Axlecenterlinedistance
3.Axlecenterline
6.6inches(15cm)ruler
3.Ifthemeasurementdoesnotfallwithinthespecied
range(refertothedimensionsandparametersatthe
beginningofthisprocedure),loosenthejamnutsat
bothendsofthetierods(Figure45).
Figure45
1.Jamnut2.Tierod
4.Rotatebothtierodstomovethefrontofthetire
inwardoroutward.
5.Tightenthetierodjamnutswhentheadjustmentis
correct.
6.Ensurethatthereisfulltravelofthesteeringwheel
inbothdirections.
MaintainingthePrimaryDrive
Clutch
Afterevery400operatinghoursoryearly,cleanand
lubricatetheclutchasfollows:
1.Stoptheengine,removethekey,andsettheparking
brake.
2.Raiseandlatchthecargobox.
3.Removethe3boltssecuringthecovertotheclutch
andremovethecover(Figure46).
Figure46
1.Cover
2.Bolts
4.Thoroughlycleantheinsideofthecoverandthe
innerworkingsoftheclutchusingcompressedair.
Thedustintheclutchwillbecomeairborneand
coulddamageyoureyesoryoucouldinhaleit
causingbreathingdifculties.
Wearsafetygogglesandadustmaskorother
eyeandrespiratoryprotectionwhenperforming
thisprocedure.
5.Lubricatethemovingpartsintheareascircledin
Figure47usingToroDryLubricantSpray,available
throughyourAuthorizedToroDealerorDistributor.
36
