Figure15
1.Parkingbrakelever
ChokeControl
Thechokecontrolislocatedbelowandtotherightof
theoperator’sseat.Tostartacoldengine,pullthechoke
controloutward(Figure16).Aftertheenginestarts,
regulatethechoketokeeptheenginerunningsmoothly.
Assoonaspossible,pushthecontrolintotheOff
position.Awarmenginerequireslittleornochoking.
Figure16
1.Choke2.Gearshiftselector
GearShiftSelector
Thegearshiftselectorhasthreepositions:forward,
reverse,andneutral(Figure16).Theenginewillstart
andruninanyofthethreepositions.
Note:IfthegearshiftselectorisinReversewhenthe
ignitionisturnedon,abuzzerwillsoundtowarnthe
operator.
Important:Alwaysstopthevehiclebefore
changinggears.
IgnitionSwitch
Theignitionswitch(Figure17),usedtostartandstopthe
engine,hastwopositions:OffandOn.Rotatethekey
clockwisetotheOnpositiontoallowoperation.When
thevehicleisstopped,rotatethekeycounterclockwise
totheOffposition.Removethekeyfromtheignition.
Figure17
1.Ignitionswitch
4.Oillight
2.Hourmeter5.PowerPoint
3.Lightswitch6.HornButton
HourMeter
Thehourmeter(Figure17)indicatesthetotalnumber
ofhourstheenginehasrun.Thehourmeterstartsto
functionwhenevertheacceleratorispressed.
OilLight
Theoillightwarnstheoperatoriftheengineoillevel
dropsbelowasafelevel(Figure17).Ifthelightcomes
onandremainslit,theoillevelshouldbecheckedand
oiladdedifnecessary;refertoCheckingtheEngineOil
inOperation,page19.
Note:Theoillightmayicker.Thisisnormalandno
actionneedstobetaken.
LightSwitch
Toggletheswitchtoactivatetheheadlights.Pushto
turnthelightson(Figure17).
PowerPoint
Usethepowerpointtopower12voltoptionalelectrical
accessories(Figure17).
HornButton
Pressthehornbuttontosoundthehorn(Figure17).
FuelGauge
Thefuelgauge(Figure18)showstheamountoffuel
inthetank.
17
