OperatingtheCargoBox
RaisingtheBox
Drivingthevehiclewiththecargoboxraised
maycausethevehicletotiporrolleasier.The
boxstructuremaybecomedamagedifyou
operatethevehiclewiththeboxraised.
•Onlyoperatethevehiclewhenthecargobox
isdown.
•Afterdumpingaload,lowerthecargobox.
1.Lifttheleveroneithersideoftheboxandliftthe
boxup(Figure23).
Figure23
1.Lever
2.Pulltheproprodintothedetentslot,securingthe
box(Figure24).
Figure24
1.Proprod
LoweringtheBox
Theweightoftheboxmaybeheavy.Handsor
otherbodypartscouldbecrushed.
Keephandsandotherbodypartsclearwhen
loweringthebox.
Pulltheproprodoutofthedetentslotandlowerthe
boxuntilitlatchesintoplace.
AdjustingtheBoxLatches
Iftheboxlatchdoesnotlatchtightly,vibratingupand
downasyoudrivethevehicle,youcanadjustthelatch
poststomakethelatchestsnugly.
1.Loosenthenutontheendofthelatchpost
(Figure25).
Figure25
1.Latch3.Latchpost
2.Nut
2.Turnthelatchpostclockwiseuntilitissnugagainst
thelatchandthentightenthenut(Figure25).
3.Repeatthisprocedureforthelatchontheotherside
ofthevehicle.
OperatingtheTailgateLatches
1.Toopenthetailgatelatches,liftthelatchhandlesup
(Figure26).Thelatcheswillspringouttowardthe
centerofthetailgate.Slowlylowerthetailgate.
Note:Youmayneedtopushtheendofthetailgate
in(especiallyifthereisaloadagainstthetailgate)
beforethelatcheswillspringtowardthecenterof
thetailgateandrelease.
