2.Loosenthesetscrewsecuringtheknobtothe
parkingbrakelever(Figure51).
Figure51
1.Parkingbrakelever
3.Setscrew
2.Knob
3.Rotatetheknobuntilaforceof30-35lb(133-156N)
isrequiredtoactuatethelever.
4.Tightenthesetscrewandinstalltherubbercover.
BeltMaintenance
ServicingtheDriveBelt
CheckingtheDriveBelt
Checktheconditionandtensionofthedrivebeltafter
therstdayofoperationandevery200operatinghours
thereafter.
1.Parkthemachineonalevelsurface,shiftinto
Neutral,settheparkingbrake,turntheignitionoff,
andremovethekey.
2.Raisethebedandsecureitwiththeproprod.
3.Rotateandinspectthebelt(Figure52)forexcessive
wearordamage.Replacethebeltifnecessary.
Figure52
1.Drivebelt
3.Secondaryclutch
2.Primaryclutch
ReplacingtheDriveBelt
1.Rotateandroutethebeltoverthesecondaryclutch
(Figure52).
2.Removethebeltfromtheprimaryclutch(Figure52).
3.Toreplacethebelt,reversetheprocedure.
AdjustingtheStarter
GeneratorBelt
Checkthetensionofthestartergeneratorbeltafterthe
rstdayofoperationandevery200operatinghours
thereafter.
1.Parkthemachineonalevelsurface,settheparking
brake,turntheignitionoff,andremovethekey.
2.Loosenthestartergeneratorpivotbolt(Figure53).
39
