FuelSystem
Maintenance
InspectingFuelLinesand
Connections
Checkthefuellinesandconnectionsevery400operating
hoursoryearly,whicheveroccursrst.Inspectthemfor
deterioration,damage,orlooseconnections.
ReplacingtheFuelFilter
Replacethefuellterevery800operatinghoursor
yearly,whicheveroccursrst.
1.Raisetheboxandsupportitwiththeproprod.
2.Placeacleancontainerunderthefuellter.
3.Removetheclampssecuringthefuelltertothefuel
lines(Figure37).
Figure37
1.Fuellter
4.Installthereplacementltertothefuellineswiththe
clampspreviouslyremoved.
Mounttheltersothatthearrowpointstowardthe
carburetor.
ElectricalSystem
Maintenance
ReplacingtheFuses
Thereare3fusesintheelectricalsystem.Theyare
locatedbeneaththebedinaboxontherighthandside
oftheframe(Figure38).
IgnitionSystem
10amp.
Lights10amp.
PowerPoint
10amp.(15amp.max.)
Figure38
1.Ignitionsystem3.Powerpoint
2.Lights
ReplacingtheHeadlights
Specication:GEHeadlight#H7610
1.Settheparkingbrake,turntheignitionoff,and
removethekey.
2.Reachbeneaththedashandpushtheheadlightout
ofthehood.
3.Removethescrewsattachingthewireharnessto
theheadlight.
4.Removetherubbersealfromaroundtheheadlight
(Figure39).Discardtheheadlight.
31
