Toro Workman 2110 - Product Overview and Controls; Key Components and Primary Controls

ProductOverview
Figure13
1.Steeringwheel
3.Parkingbrake
5.Cargobox7.Cargoboxreleaselever
2.Gearshiftselector
4.Fuelcap6.Towingtongue
Controls
AcceleratorPedal
Theacceleratorpedal(Figure14)givestheoperatorthe
abilitytovarygroundspeedofthevehicle.Pressing
thepedalstartstheengine.Pressingthepedalfarther
increasesgroundspeed.Releasingthepedalwillslow
thevehicleandtheenginewillstoprunning.Maximum
forwardspeedis16mph(26km/h).
Figure14
1.Acceleratorpedal2.Brakepedal
BrakePedal
Thebrakepedalisusedtostoporslowthevehicle
(Figure14).
Brakescanbecomewornorcanbemisadjusted
resultinginpersonalinjury.
Ifbrakepedaltravelstowithin1inch(25mm)
ofthevehicleoorboard,thebrakesmustbe
adjustedorrepaired.
ParkingBrake
Theparkingbrakeisbetweentheseats(Figure15).
Whenevertheengineisshutoff,theparkingbrake
mustbeengagedtopreventaccidentalmovementof
thevehicle.Toengagetheparkingbrake,pullbackon
thelever.Todisengage,pushtheleverforward.Ifthe
vehicleisparkedonasteepgrade,makesurethatthe
parkingbrakeisapplied.Placeblocksatthedownhill
sideofthewheels.
16
