Figure39
1.Rubberseal
3.Outsidenotch-alignwith
notchinhood
2.Insidenotch-alignwiththe
notchontheheadlight
4.Headlight
5.Alignthenotchontheinsideofthesealwiththe
notchonthenewheadlight(Figure39).Slidetheseal
ontotheheadlightuntilthesealisrmlyinplace.
6.Attachtheheadlighttothewireharnessusingthe
previouslyremovedscrews.
7.Alignthenotchontheoutsideofthesealwiththe
notchinthehood.Pushtheheadlightandsealinto
thehooduntilitisrmlyinplace.
Note:Applyingsoapywatertotheoutsideofthe
sealmayaidinslidingthesealintothehood.
ServicingtheBattery
Warning
CALIFORNIA
Proposition65Warning
Batteryposts,terminals,andrelated
accessoriescontainleadandleadcompounds,
chemicalsknowntotheStateofCalifornia
tocausecancerandreproductiveharm.
Washhandsafterhandling.
Important:Donotjumpstartthevehicle.
Alwayskeepthebatterycleanandfullycharged.Use
apapertoweltocleanthebatteryandbatterybox.If
thebatteryterminalsarecorroded,cleanthemwitha
solutionoffourpartswaterandonepartbakingsoda.
Applyalightcoatingofgreasetothebatteryterminals
topreventcorrosion.
Voltage:12voltwith280coldcrankingAmps@0°F
(-18°C).
RemovingtheBattery
1.Positionthevehicleonalevelsurface,settheparking
brake,turntheignitionoff,andremovethekey.
2.Raisethebedandsecureitwiththeproprod.
3.Removethebatteryhold-down.
4.Disconnectthenegative(black)groundcablefrom
thebatterypost.
Incorrectbatterycableroutingcoulddamage
thevehicleandcables,causingsparks.Sparks
cancausethebatterygassestoexplode,
resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysreconnectthepositive(red)battery
cablebeforereconnectingthenegative
(black)cable.
•Alwayskeepthebatterystrapinplaceto
protectandsecurethebattery.
Batteryterminalsormetaltoolscouldshort
againstmetalvehiclecomponents,causing
sparks.Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,do
notallowthebatteryterminalstotouchany
metalpartsofthevehicle.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
vehicle.
5.Disconnectthepositive(red)cablefromthebattery
post.
6.Removethebatteryfromthechassis.
InstallingtheBattery
1.Setthebatteryonthebatterybasesothebattery
postsaretowardtherearofthevehicle.
2.Connectthepositive(red)cabletothepositive(+)
batterypostandthenegative(black)cabletothe
negative(-)batterypostusingtheboltsandwing
32
