5-36 Z Master Z400 Service Manual
5
ENGINE
10. Unplug the electric PTO clutch plug (Fig. 342).
Fig 342 PICT-0405
Fig 344 PICT-0407
12. Remove the fuel hose clamp on the fuel hose
located at the fuel pump (Fig. 344).
Fig 343 PICT-0406
11. Turn the fuel shut-off valve to the “off” position (Fig.
343).
13. Unplug the violet wire from the B+ side of the
regulator (Fig. 345).
Fig 345 PICT-0408
